Isolated design PU insulation stainless steel water storage tanks for juice and beer storage
Steel storage tank is a special equipment for storing all kinds of liquid (or gas) raw materials and finished products. For many enterprises, normal production can not be achieved without storage tank, especially the national strategic material reserve is inseparable from all kinds of capacity and type of storage tank. Most of the oil storage facilities in China are above ground tanks, and most of them are metal structures.
Double layer tank
Usage: mainly applicable for storaging and mixing of all kinds of liquid products like: dairy products, juice, beer and brew, chemistry liquid , and biology engineering products, etc;
Specifications:
Material: All material used is high quality sus304-2B stainless steel or SUS316, inner shell thickness δ=3-4mm, outer shell δ=2mm
Structure feature: Isolated design(double layer),with 50-60mm PU as insulation; cylindrical shape, triangle or cylinder legs.
Agitator types: with or without agitator; with agitator: wing agitator; anchor type; propeller type; frame type;
Standard configuration
a). One air tight side manhole;
b). Anti butterfly and dirt air vent;
c). One PT100 thermometer, temperature range 0~100℃;
d). CIP cleaning ball;
e). Product inlet/outlet;
f). Discharge valve
g). Adjustable legs;
h). Sample valve
Technical parameter
| Model | Volume(L) | External diameter | Height (mm) | PU Insulation (mm) | Diameter of inlet/outlet |
| BYDG-500 | 500 | 800 | 2140 | 50 | φ38 |
| BYDG-1 | 1000 | 1050 | 2380 | 50 | φ38 |
| BYDG-1.5 | 1500 | 1180 | 2550 | 50 | φ38 |
| BYDG-2 | 2000 | 1340 | 2760 | 50 | φ38 |
| BYDG-2.5 | 2500 | 1420 | 2940 | 50 | φ38 |
| BYDG-3 | 3000 | 1540 | 3050 | 50 | φ38 |
| BYDG-4 | 4000 | 1650 | 3200 | 50 | φ38 |
| BYDG-5 | 5000 | 1780 | 3250 | 50 | φ38 |
| BYDG-6 | 6000 | 1900 | 3350 | 50 | φ38 |
| BYDG-8 | 8000 | 2100 | 3800 | 60 | φ65 |
| BYDG-10 | 10000 | 2300 | 4050 | 60 | φ65 |
| BYDG-12 | 12000 | 2520 | 4450 | 60 | φ65 |
| BYDG-15 | 15000 | 2540 | 4700 | 60 | φ65 |
Description:
Shanghai beyond machinery Co., Ltd is specialized in supplying various kinds of milk processing line, including the pasteurized milk, UHT milk, flavored milk, yoghurt, cheese and butter, cream, condensed milk etc.
Shanghai Beyond can supply complete turnkey projects for customers, integrating with designing, equipment manufacturing, to installation and commissioning and also training the operators.
Pasteurized milk process: milk transporting, milk filtering and collection; cooling and storaging, cream separation, pasteurization, homogenization, degassing, and filling.
| Minimum Order Quantity: | One set/one line |
| Price: | negotiation |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 Sets Per Season |
| Delivery Time: | 50-100 working days upon receipt of payment and confirmed the drawings |
| Packaging Details: | PE film wrapping, or carbon steel frame packing, or wooden case packing as to clients’ requirement |
| Warranty | 12 months after commissioning |
|
After sales service | Engineers available to service machinery overseas |
FAQ:
1 ) Q: How can we visit your factory?
A: If you come from abroad, air to shanghai airport, then we can pick you up at airport.
2) Q: How do you ensure the quality of your products?
A: Our Company is a state owned enterprise with more than 16 years experience , strict operation policy is performed, advanced processing machines guarangtee the precision of all components, workers with operation license, parts get multiprocessing, transmission& electrical parts are of international famous brand. Series of test and inspection are done in the whole producing state.
3) Q: What payment methods your company accept?
A: We accept most of the payment methods , but mainly accept T/T, L/C at sight .
4) Q: How long is the warranty time for your products?
A: Our officially promised warranty time is 12 months after commissioning .
5) Q: I am new in this field,can you supply us turnkey services?
A: YES.We can supply all the system including Market Analysis/Product Analysis/Location Choice/Processing Flow Design/Equipment Layout Design/Building Design direction/Equipment mode selection/Equipment Manufacturing/Equipment Mounting/Equipment Debugging/Worker Training.
6) Q: What ' s the shipment terms and delivery time of your company?
A: Well, the delivery time depend on the quantity of your order. Usually is 20 days . For some customized machine 30 days is necessary.
7) Q: Can you supply OEM services?
A: Yes,we have our R&D team,and we have more than 400 workers with workshop area 75000 square meters.
8) Q: Do you give any Discount?
A: I will surely try my best to help you get those by the best price and good service at the same time.
